Caston III Plus - 20,000 lb x 5 lbs Crane Scale
CAS 20,000 lb crane scale



Alternative Views:
Our Price: $3,295.00



Product Code: CAS-CASTON-III-20K


Bluetooth Option:

Qty:
OVERVIEW MANUAL/BROCHURES

The Caston III Crane Scale is a rugged heavy duty, easy to use crane scale ideal for use in harsh industrial environments. With capacities up to 100,000 lbs, the Caston 3 Crane Scale works well in light to medium industrial applications. It comes equipped with a wireless remote control. Add the TWN-B and THD-BT to utilize the Caston 3 Series bluetooth capabilities.

The CASTON III PLUS is a full featured, rugged industrial crane scale with standard features that include a watertight enclosure, 1.5” high intensity LED display, simple, easy to use rechargeable battery pack, wireless remote control, swivel hook, and portable hand held indicator.

  • 20,000 lb x 5 lbs
  • Comes equipped with a wireless remote control.
  • Accuracy Plus or minus 0.1% of applied load
  • Maximum Tare Full Tare
  • Overload Safety: 150% of rated capacity
  • Ultimate: 300% of rated capacity
  • Housing: Alodined cast aluminum, Double O-ring gasket, NEMA 4 IP 65
  • Hook, Eye, Shackles: Crosby or equivalent
  • Display Type: LED / 6 Digit (1.5 inch)
  • Frequency (BT): 2.4 Ghz
  • Remote Distance (BT): Up to 350 ft / 106.7 m
  • Channels (BT): Up to 79 separate channels
  • Calibration: Manual
  • Operating Power: DC 12V Rechargeable Battery Pack
  • Operating Time: 14 - 24 hours
  • Power Source: AC 120V, 50/60 Hz
  • Display Designators: Zero, Tare, Hold, Batt
  • Power Consumption: 1.2 W
  • Operating Temp: -10°C ~ 40°C / 14°F ~ 104°F
  • Warranty: 2 Years
